Zeus is the next evolution that the SoftWash industry has been asking for. Higher flow, higher pressure, and a higher reach are what make the Zeus SmoothFlo pump the top choice for standard and heavy duty bleach and SoftWash applications.
AVAILABLE THROUGH DISTRIBUTION
SUMMER 2024
PRESSURE SETTING: 150 PSI DUAL CONTROL
OPEN FLOW RATE: UP TO 14 GPM
TECHNICAL INFORMATION
- 1" FNPT PORTS
- 24 VDC - 10 AWG 12" WIRE LEADS
- VERTICAL SELF PRIMING UP TO 14FT
- 140°F (60°C) MAX LIQUID TEMPERATURE
- 180°F (82°C) MAX MOTOR SHELL TEMPERATURE
- HEAVY DUTY FAN COOLED MOTOR
- 100% FACTORY TESTED PERFORMANCE
- DRY RUN CAPABLE
SPRAY SYSTEM RECOMMENDATIONS
- 3/4" HOSE RECOMMENDED, MINIMUM HOSE SIZE 5/8"
- 250FT MAXIMUM HOSE LENGTH
- SIZE 60 SPRAY TIPS FOR 100 PSI OPERATING PRESSURE
- SIZE 40 SPRAY TIPS FOR 125 PSI OPERATING PRESSURE
- DO NOT USE TIPS SMALLER THAN SIZSE 40
- 50 AMP FUSE RECOMMENDED
- PRESSURE GAUGE TO AID WITH SYSTEM MONITORING
TYPICAL APPLICATIONS
- SOFTWASH APPLICATIONS
- WASHDOWN AND DUST SUPPRESSION
- AG AND INDUSTRIAL SPRAYING WITH COMMON CHEMICALS
COMMON ACCESSORIES
RACT-820-NPT
PULSATION DAMPENER ACCUMULATOR
901-RC02-R
24 VDC REMOTE ON/OFF SWITCH
PUMP PERFORMANCE
TECHNICAL INFORMATION
- 1" FNPT PORTS
- 24 VDC - 10 AWG 12" WIRE LEADS
- VERTICAL SELF PRIMING UP TO 14FT
- 140°F (60°C) MAX LIQUID TEMPERATURE
- 180°F (82°C) MAX MOTOR SHELL TEMPERATURE
- HEAVY DUTY FAN COOLED MOTOR
- 100% FACTORY TESTED PERFORMANCE
- DRY RUN CAPABLE
SPRAY SYSTEM RECOMMENDATIONS
- 3/4" HOSE RECOMMENDED, MINIMUM HOSE SIZE 5/8"
- 250FT MAXIMUM HOSE LENGTH
- SIZE 60 SPRAY TIPS FOR 100 PSI OPERATING PRESSURE
- SIZE 40 SPRAY TIPS FOR 125 PSI OPERATING PRESSURE
- DO NOT USE TIPS SMALLER THAN SIZSE 40
- 50 AMP FUSE RECOMMENDED
- PRESSURE GAUGE TO AID WITH SYSTEM MONITORING
TYPICAL APPLICATIONS
- SOFTWASH APPLICATIONS
- WASHDOWN AND DUST SUPPRESSION
- AG AND INDUSTRIAL SPRAYING WITH COMMON CHEMICALS
PUMP PERFORMANCE
COMMON ACCESSORIES
RACT-820-NPT
PULSATION DAMPENER ACCUMULATOR
901-RC02-R
24 VDC REMOTE ON/OFF SWITCH
TECHNICAL INFORMATION
- 1" FNPT PORTS
- 24 VDC - 10 AWG 12" WIRE LEADS
- VERTICAL SELF PRIMING UP TO 14FT
- 140°F (60°C) MAX LIQUID TEMPERATURE
- 180°F (82°C) MAX MOTOR SHELL TEMPERATURE
- HEAVY DUTY FAN COOLED MOTOR
- 100% FACTORY TESTED PERFORMANCE
- DRY RUN CAPABLE
SPRAY SYSTEM RECOMMENDATIONS
- 3/4" HOSE RECOMMENDED, MINIMUM HOSE SIZE 5/8"
- 250FT MAXIMUM HOSE LENGTH
- SIZE 60 SPRAY TIPS FOR 100 PSI OPERATING PRESSURE
- SIZE 40 SPRAY TIPS FOR 125 PSI OPERATING PRESSURE
- DO NOT USE TIPS SMALLER THAN SIZSE 40
- 50 AMP FUSE RECOMMENDED
- PRESSURE GAUGE TO AID WITH SYSTEM MONITORING
TYPICAL APPLICATIONS
- SOFTWASH APPLICATIONS
- WASHDOWN AND DUST SUPPRESSION
- AG AND INDUSTRIAL SPRAYING WITH COMMON CHEMICALS
PUMP PERFORMANCE
COMMON ACCESSORIES
RACT-820-NPT
PULSATION DAMPENER ACCUMULATOR
901-RC02-R
24 VDC REMOTE ON/OFF SWITCH
INFORMATIONAL VIDEOS
PRODUCT DOCUMENTS
PUMP CONFIGURATIONS
| Item Number | Flow | Controls | Pressure | Ports | Voltage | Spec Sheets |
|---|---|---|---|---|---|---|
|
9559-9K5-971 |
14 GPM (52.9 LPM) |
Dual |
150 PSI (10.3 BAR) |
1" FNPT |
24 VDC |
Coming Soon |
